Vetoo VT-FPDW1

1717 WIRED X-RAY FLAT PANEL

17 X 17 portable cassette-sized flat panel detector
Stable and reliable AED (Automatic Exposure Detection)
Anti-collision and water proof structure (IPX4)
Flat panel detector technology offers cutting-edge solutions for various imaging applications, particularly in the medical and industrial sectors. Designed to deliver high-resolution images with enhanced clarity and accuracy, these detectors are essential in modern X-ray systems. The flat panel detector provides superior image quality, faster processing times, and improved reliability, ensuring better diagnostic capabilities and efficiency for healthcare professionals and technicians.

In addition to healthcare, flat panel detectors are used in industrial radiography for non-destructive testing. These detectors are known for their robust design, which can withstand harsh environments, and their ability to capture detailed images for material inspection, structural assessments, and quality control. Their compact design makes them versatile for various applications.

As industries continue to demand high-quality imaging solutions, the flat panel detector remains a key tool for precise, quick, and reliable results.

Specifications

Model No.	VT-FPDW1 (1717 wired)
Technology	A-Si TFT
Scintillator	CSI
Pixel Pitch	139 um
Grayscale	16bit
Image Acquisition Time	2S
Recommended Cycle Time	5S
Pixel Matrix	3072x3072 pixs
Active Area	430mmx430mm
Spatial Resolution	3.5lp/mm
Dimension(HxWxD)	380x460x1 5.5(mm)
Weight	4.2 KG
Battery	/
Operating environment	temperature: 5° -35° , humidity: 30-80% RH(non-condensing)
Storage environment	temperature: -10° -55° , humidity: 15-90% RH(non-condensing)
Soft Trigger	Soft trigger/AED
